SWITCH/D-LINK/DGS-F1100-10PS 8 PORTS POE SMART WITH 2 PORTS SFP

General Specifications

Model: D-Link DGS-F1100-10PS

Type: Smart Managed Switch

Ports:

8 x 10/100/1000 Mbps PoE+ ports

2 x 1G SFP (Small Form-Factor Pluggable) uplink ports

PoE Standard: IEEE 802.3af/at

Total PoE Budget: 96W

Performance Specifications

Switching Capacity: 20 Gbps

Forwarding Rate:

14.88 Mpps (for 1000 Mbps)

MAC Address Table: 8,000 entries

Jumbo Frame Support: Up to 9,216 bytes

Power Specifications

Power Supply:

AC 100-240V, 50/60Hz

Power Consumption:

Maximum 100W (including PoE)

Physical Specifications

Form Factor:

Rackmount (1U) and desktop placement

Dimensions:

280 mm x 180 mm x 44 mm (11.02 in x 7.09 in x 1.73 in)

Weight:

Approximately 1.5 kg (3.31 lbs)

Cooling:

Fanless design for silent operation

Environmental Specifications

Operating Temperature:

0°C to 50°C (32°F to 122°F)

Storage Temperature:

-40°C to 70°C (-40°F to 158°F)

Operating Humidity:

10% to 90% non-condensing

Storage Humidity:

5% to 90% non-condensing

Management Features

Management Type: Smart Managed

Management Interface:

Web-based GUI for easy configuration

VLAN Support:

802.1Q VLAN tagging

Quality of Service (QoS):

Supports traffic prioritization

IGMP Snooping:

For multicast traffic management

Port Mirroring:

For network monitoring

Security Features

Port Security:

Prevents unauthorized access

Static MAC Address Support:

Enhances network security

Storm Control:

Prevents broadcast storms

Additional Features

D-Link Green Technology:

Energy-efficient design

Automatic Power Adjustment:

Based on cable length

LED Indicators:

For power, link/activity, and PoE status
